Red bean and coix seed powder production equipment, cereal powder/porridge production line (Datong Machinery) is our company's nutritional powder production line. On the basis of absorbing foreign technology, we independently developed a highly automated nutritional powder production line. It combines traditional whole grains with It is extruded using high temperature and high pressure to denature the starch in the raw grain, which is more conducive to human body absorption and has higher nutritional value than traditional processing techniques.
【raw material】
Using rice, corn, oats, barley, red beans, tartary buckwheat, etc. as the main raw materials and adding various nutrients
【product】
Breakfast porridge, cereal porridge, beans, sesame, etc.
【Production Process】
Raw material preparation → Mixing → Extrusion and puffing → Screening → Lifting → Drying and sterilization → Cooling → Crushing → Mixing → Packaging
【Device Configuration】
Powder mixer → Screw feeder → Twin-screw extruder → Vibrating screen → Elevator → Multi-layer oven/microwave drying → Cooling line → Crusher → Mixer → Packaging machine
【Technical Parameters】
The specific production line configuration is determined based on the actual situation of the customer and specific products.
Model | total power | actual energy consumption | Yield | size |
DT65 | 70 kw | 50 kw | 100-160 kg/hr | 16x1.3x2.2(m) |
DT70 | 82 kw | 65 kw | 200-260 kg/hr | 17x1.3x2.2(m) |
DT85 | 152.75 kw | 130 kw | 300-500 kg/hr | 20x1.5x2.2(m) |
DT90 | 156.25 kw | 130 kw | 800-1200 kg/hr | 24x1.5x2.6 (m) |
DT95 | 171.25 kw | 150 kw | 1000-1800 kg/hr | 30x1.5x2.6 (m) |
