Introduction: Breakfast cereals and snack snacks are crispy foods with a smooth texture and a rich cereal flavor. Breakfast cereals are processed by an extruder with a special structure. Compared with the traditional method, the output, quality, and raw material adaptability are further improved, making it possible to fortify trace elements such as vitamins and minerals. This production line has the characteristics of multiple optional models, flexible equipment configuration, wide range of raw materials, multiple product types, and simple operation. By changing different molds and changing the production process, various puffed foods popular on the market can be produced, which is suitable for various food manufacturers.
1. Oat cake food production line process flow:
Preparation of raw materials → Mixing powder → Conveying → Extrusion and puffing → Conveying → Drying → Oil spraying → Seasoning → Packaging
2. Equipment configuration of puffed crispy snack food production line:
Mixing machine → feeding machine → puffing machine → air conveyor → multi-layer oven → elevator → fuel injection machine → roller → packaging machine
3. There are three main types of oatmeal puffing equipment production lines. Currently, the SLG65-III production line is generally available on the market.
Model parameters | SLG65-Ⅲ snack food equipment | SLG70 puffed food equipment | SLG85 food puffing machine |
monitor rate | 22KW | 45KW | 90KW |
Installed capacity | 70KW | 100KW | 170KW |
Actual power consumption | 45KW | 70KW | 100KW |
production capacity | 120-150kg/h | 220-260kg/h | 300-400kg/h |
Dimensions | 14×1.3×2.4 | 16×1.3×2.4 | 18×1.3×2.4 |
4. Process composition of puffed oat cake food production equipment:
1. Flour mixing machine: fully mix corn flour, flour, rice flour and other raw materials with additives and a certain amount of water evenly.
2. Feeding machine: transport the mixed raw materials to the feeding hopper of the extruder.
3. Extruder: The raw materials enter the extrusion system from the feeding hopper, and products are produced in a high-temperature and high-pressure environment (the products are diverse and can be configured differently according to the product).
4. Multifunctional rice cake forming machine: The compression forming machine is mainly suitable for producing rice krispie treats, sesame candy and other special-shaped foods.
This machine consists of five parts: laying, molding, cooling, demoulding, cooling and conveying. The ML100 rotary table stamping machine has the advantages of simple operation, convenient use, large production volume, multiple replaceable molds, and small floor space.
5. Multi-layer oven: Most ovens are electric ovens. The temperature can be adjusted by the control cabinet between 0-200 degrees. The interior is a stainless steel double-layer mesh bag. The baking time can be adjusted according to the speed. There are three layers, five layers, and seven layers. stainless steel oven;
5. Company after-sales service
1. The company’s after-sales service personnel can provide ingredients and basic product formulas for related products.
2. Provide on-site training to relevant personnel of the purchaser on equipment operation and regular maintenance.
3. Regularly visit customers via after-sales calls to help you solve related problems encountered during the use of the equipment.
4. Our company provides high-quality and low-cost spare parts to buyers all year round, and provides equipment upgrades and new product development support.
5. If the equipment is damaged after the warranty expires, users in the province will arrive at the repair site within two days after receiving notification from the purchaser. Users outside the province negotiate with technical personnel and strive to arrive at the site in a short time. For out-of-warranty equipment, the company will charge service and spare parts replacement costs.
6. If the equipment is damaged due to non-human factors during the warranty period, the company will provide free repairs. For equipment damage caused by human factors and force majeure factors, the company provides maintenance services but charges relevant fees.
